Computer motherboard
Craft show
| Layers | 8L |
| Board thickness | 1.6mm |
| Material | IT180A+IT170GRA2 |
| Line width / space | 0.086/0.081mm |
| Minimum laser drilling aperture | 0.2mm |
| Surface treatment | OSP |
With the increasing demand for cloud computing, big data, social contact, entertainment, and mobile computer equipment, our work efficiency has been greatly improved, and our lifestyles and entertainment have also been enriched. Meanwhile, both our modern social work and life experience have also been promoted. In addition, with the growing demand for online office and online education, there has been a significant increase in the shipment of computers and the supporting industry.
Suntak Technology's key production capacity planning for computer products is centered at its Zhuhai F2. Zhuhai F2 is a modern smart factory with a high degree of informatization and automation, which, leveraging the comprehensive technical strength and years of manufacturing experience accumulated by the group company, can produce various types of PCB products for use in computers, such as motherboards, graphics cards, monitors, memory, hard drives, mice/keyboards, and more.
Craft show
| Layers | 8L |
| Board thickness | 1.6mm |
| Material | IT180A+IT170GRA2 |
| Line width / space | 0.086/0.081mm |
| Minimum laser drilling aperture | 0.2mm |
| Surface treatment | OSP |
Craft show
| Layers | 10L |
| Board thickness | 1.1±0.11mm |
| Material | H170HF |
| Size | 229.9 x 350.8mm |
| Line width / space | 0.075/0.075mm |
| Surface treatment | OSP |
| Special design | 0.075/0.075 line |
Craft show
| Layers | 10L |
| Board thickness | 1.57±0.13mm |
| Material | IT170GRA1 |
| Line width / space | 0.1/0.1mm |
| Minimum laser drilling aperture | 0.2mm |
| Surface treatment | OSP |
| Special design | NA |
Craft show
| Layers | 2L |
| Board thickness | 0.41±0.038mm |
| Material | IT150GTC |
| Line width / space | 0.1/0.1mm |
| Minimum laser drilling aperture | 0.2mm |
| Surface treatment | OSP |
Craft show
| Layers | 8L |
| Board thickness | 1±0.1mm |
| Material | S100H |
| Line width / space | 0.076/0.076mm |
| Minimum laser drilling aperture | 0.2mm |
| Surface treatment | Selective Gold+OSP |
Craft show
| Layers | 10（3+4+3） |
| Board thickness | 0.064±0.018mm |
| Material | EMC EM-390 |
| Line width / space | 0.055/0.045mm |
| Minimum laser drilling aperture | 0.25mm |
| Surface treatment | ENIG |
Craft show
| Layers | 10 |
| Board thickness | 0.076±0.018mm |
| Material | ITEQ IT150GTC |
| Line width / space | 0.11/0.06mm |
| Minimum laser drilling aperture | 0.203mm |
| Surface treatment | OSP |
We use raw materials from world famous brands, have established incoming material inspection regulations that comply with international and customer standards, constantly trace and promote supplier quality improvement activities, and build and maintain strong cooperation with suppliers.
Quality products are made, not tested. We have standardized production process and detailed operation instructions for each process of the production line to ensure that the operation specifications and operation standards are correctly implemented.
We strictly check and control the shipment quality according to the international standards and customer standards, timely follow up the product quality performance after shipment, and take quick and effective improvement actions on the customer
Responsible for managing the supplier and incoming materials
Responsible for promoting all systems of the company as well as the maintenance and the import of new customers
Responsible for the first article inspection of the process, the patrol inspection, and taking the lead in improving process abnormality and managing defective products
Responsible for monitoring the solution in the production line and the reliability of products
Responsible for the inspection before delivery
Responsible for after-sales service
The products of Zhuhai F2 primarily consist of high multilayer boards
